06ExtendedFunctionsMenu
With“SetDefaults”itispossibletoresetallsettingstothedeliverystatus.
Theresetisinitiatedbyselectingthemenuanpressingabutton.Toavoidunintended
resettingtheuserhastoconfirmtheprocedurebyagainpressingthebuttonwhen
“confirm”isdisplayed.“Process”showsthattherestisperformed.
MostofthedefaultsarelistedintheoverviewdiagramoftheExtendedFunctionsMenu.
Thosesettingsmissingthereare:
Power:
Temperature:
HeaterControlMode:
WireType:
The canbeusedin5differentmodes.Butinordertokeepthemenu
asshortandsimpleaspossible,3ofthe5modesareonlyavailable,iftheExpert-Mode
issetto1.ThenameisExpert-Mode,becausetheuseoftheadditionaloperationmodes
requiresadditionalknowledgeabouttheirfunctionality.
dicodesDaniBoxes
TheadditionalmodesavailablewithExpertModesetto1are“PowerBoost”,“HeaterProtection”and
“Bypass”.
Hereagainthemodesinanoverview:
AdditionalExplanationtoseveralmenuitems,page2
10W
210°C
0(Power,normalVW)
NiFe(320)
Vapingwithaconstantpowersetting.Theselectedpowerisappliedtothecoil,unless
thecoil’sresistanceaffordsadifferentpowersettingorpowerislimitedduetoother
reasons..
Thepowerappliedtothecoiliscalculatedbyatemperaturecontrollerwhichkeepsthe
coil’stemperatureconstant.Importanttonote:Setthecorrecttemperaturecoefficient
andperformacalibrationatroomtemp.
Thecoilisquicklyheatedupinitially.Moreoveranrepetitiveboostcanbeselected.
Werecommendnottosettheboost-powervaluetoolowbutadjustalowernormal
powersettingtolimitthecoilstemperaturerise.
Thepowerappliedtothecoilisrepetivelyinterruptedtoenablealiquidflowundthusto
limitthetemperature.
Themodbehaveslikeamechanicalmod,i.e.thebatteryvoltageisdirectlyappliedtothecoil.
This,withtherestriction,thatthemaximumcurrentis22A.Notethatthevapenowdepends
onthecharginglevelofthebattery,andthecoilshouldnotbetoolowinresistanceasthen
22Aisthelimitingfactor.IftheresistanceistoolowinBypass-mode,Err8LowRisdisplayed
andvapingisnotpossible.
Thedisplaymodeswitchesonandoffthedynamicdisplayofseveralparametersduring
andafterthepuff.Thesetting“cont”(continous)willdisplayvaluesduringand4seconds
afterthevape.With“post”thevaluesaredisplayedonlyafterthepuffandoffdisables
thedisplay.
Thevaluesshowndependontheoperationmode:Intemperaturecontrolledmode,theparametersare
thetemperature,coilresistance,temperatureregulatingpowerandabatterysymbol.
Forthemodespower,boostandheaterprotection,theselectedpower(orlimitedpowerincase),thecoil
resistanceandthebatteryvoltagearedisplayed.WhenBypassmodeisselected,thecoilresistanceand
thebatteryvoltagedependent,measuredpowerisdisplayed,asthereisnofixedpowersettingin
bypassmode.
Mode0
Power
Mode1
Temp-Cont.
Mode2
Heater-Prot.
Mode3
Power-Boost
Mode4
Bypass
