- INDICATOR DI-28SS -
Overview
DI-28SS is a microprocessor chip good for all kinds of weighing application for Bench
Scale , Floor Scale and Platform Scale . It is very high accuracy and use re-charge
battery operate up to 120hrs . It is a new design for weighing indicator with build–in
series output RS-232c.
Features :
1. Accuracy class：C-III.
2. A/D conversion speed：20 times/second.
3. Internal resolution 1/ 300,000.
4. Display resolution ：1/1000～1/30,000 division.
5. Non linearity：＜0.016％F.S.
6. Rated Output：0~20mV.
7. Excitation Voltage：＋
DC5V，Analog (up to 4 x 350Ω load cell) .
8. Power supply：DC6V/4Ah re-charge battery or AC230V power supply.
9. Display：6 digits LED display and height 25mm LED.
10. LED indicate ：G.W., N.W., tare, zero, ct, oz, lb, kg.
11. Power consumption：1W.
12. Operating temperature：0 ~ 40 .
13. Humidity：≤ 85％.
14. Dimension：230mm × 145mm × 98mm.
15. Weight：1.5 kg.
