1. Digitrax® specicaon for reporng 'short' locomove addresses.
Standard: Report 0x7D in high quality byte.
Alternave: Report 0x00 in high quality byte.
2. Block addresses are sent by Digitrax® only in even numbers. However,
the DR5013 can also send linear (even and odd) block addresses, ex-
tending the reporng range by 2048.
3. Report the speed of the locomoves to the control centre via Rail-
com®.
4. To prevent too many messages from being sent to the central unit
when the value changes quickly, a "Delta" value can be set here.
(*See example)
5. Report the signal quality of the Railcom® messages to the control cen-
tre.
The messages are reported by the decoder in %.
0% All commands have arrived (track or locomove clean).
100% of the commands have not arrived (track or locomove
dirty).
4.4.2 Module Properes
6
7
6. All QoS messages below this value are not reported to the central
unit.
7. A "Delta" value can be set here so that too many messages are not
sent to the central unit when the value changes quickly.
8. „"Report the "tank contents" of the locomoves to the central unit via
Railcom®.
*Example:
1. last measured value =10
newly measured value =6 Delta = 4
2. last measured value =3
newly measured value =9 Delta = 6
3. last measured value =12
newly measured value =1 Delta = 11
Parameter "Delta" = 6 The values 2. and 3. are reported, 1. is suppressed.
Noce! Not all funcons are supported by all decoders. Please refer to the
respecve decoder manual for details.
