Digikeijs DR5088RC DIGIDETECT - Hardware Overview

DR5088RC DIGIDETECT 30.05.2019
P 7
www.digikeijs.com
1 Railcom® Detector 1 - 8
2 Railcom® Global Detector
3 Railcom® Detector 9 - 16
4 Module address programming buon
5 Module LED indicator
Standard blinker: Heart rate module
Short blinker/long on: Module address recepon
6 USB 2.0 connecon
7 USB acviteit
Green: RX
Red: TX
8 Track voltage input
9 LocoNet® connecon
10 LocoNet® connecon
1
2
3
4
8 9 10
2.3 Hardware overview
7 6 5
