Digilent Analog Discovery - Compatible Products; About this Document; Functional Description; Connectors and Jumpers

Pass through Connector for the Digital I/O Signals
Compatible with the Analog Discovery 2 and Analog Discovery (Legacy)
Compatible Products
The Analog Discovery Audio Adapter is compatible with the following:
Analog Discovery 2
Analog Discovery (Legacy)
About this Document
This reference manual applies to Revision B of the Analog Discovery Audio Adapter.
Functional Description
Connectors and Jumpers
Label Name Description
J1 2×15 Analog
Discovery
connector
Interfaces the Audio Adapter with the Analog Discovery
J2 2×15 Analog
Discovery
connector
Used for passing through the unused signals of the
Analog Discovery
J3 Mono/Stereo Jack
connector
Used to connect a mono or a stereo audio source to
the inputs of the Analog Discovery scope
J4 Mono Jack
connector
Used to connect a mono audio source to the inputs of
the Analog Discovery scope
JP1 Mono/Stereo
Selection Jumper
Used to select if through J3 will pass a mono or stereo
signal
Visualizing the Audio Signals
The Analog Discovery Audio Adapter is used to analyze the audio signals taken from an
external source or from the Analog Discovery. It uses the Oscilloscope device
instrument. If the audio signals are generated by the Analog Discovery, a 3.5mm male
jack stereo cable needs to be connected to the stereo input of the audio adapter. The
