EVO Control Panel 49
4.1.5 Exit Confidential Mode
Section [009] Option [2]
Option [2] ON = Exit Confidential Mode by entering an access code.
Option [2] OFF = Exit Confidential Mode by pressing a button (default).
Option [2] must be set to ON on UL listed systems.
Option [2] will only work if option [1] is enabled.
4.1.6 Confidential Mode Timer
Section [012]
Section [012] determines the amount of time without action before the
keypad enters Confidential Mode. The Confidential Mode Timer can be set
from 005 seconds to 255 seconds. Default: 120 seconds
4.1.7 Muting
Section [009] Option [3]
Option [3] OFF = Audible sounds (default).
Option [3] ON = Mute.
4.1.8 Beep on Exit Delay
Section [009] Option [4]
Option [4] OFF = Exit Delay beep disabled.
Option [4] ON = Exit Delay beep enabled (default).
4.1.9 Chime on Zone Closure
Section [009] Option [5]
Option [5] OFF = Chime on Zone Closure disabled (default).
Option [5] ON = Chime on Zone Closure enabled.
4.1.10 Beep on Trouble
Section [010] Options [1] To [4]
System Troubles / Clock Loss
Option [1] OFF = Disabled (default).
Option [1] ON = Enabled.
Communicator Troubles
Option [2] OFF = Disabled (default).
Option [2] ON = Enabled.
Module / Communication Bus Troubles
Option [3] OFF = Disabled (default).
Option [3] ON = Enabled.
Zone Troubles
Option [4] OFF = Disabled (default).
Option [4] ON = Enabled.
4.1.11 Keypad Anti-tamper Enable
Section [011] Option [5]
Option [5] OFF = Keypad's anti-tamper is disabled (default).
Option [5] ON = Keypad's anti-tamper is enabled.
4.2 Programmable Output Options
4.2.1 PGM State
SECTION [011] OPTION [1]
The PGM is limited to 50mA.
Option [5] OFF = PGM is Normally Open (default).
Option [5] ON = PGM is Normally Closed.
4.2.2 PGM Activation Event
SECTION [014] to [017]
Enter the sections that correspond to the
EVENT GROUP, FEATURE GROUP,
START # and END # of the PGM and enter the required data.
4.2.3 PGM Deactivation Event
SECTION [018] to [021]
If the PGM Deactivation Option is set to follow the PGM Deactivation Event,
the PGM will return to its normal state when the event programmed in
sections [018] to [021] occurs. Enter the sections that correspond to the
EVENT GROUP, FEATURE GROUP, START # and END # of the PGM and enter
the required data.
4.2.4 PGM Deactivation Mode
SECTION [011] Option [2]
Option [2] OFF = Deactivation as per PGM Deactivation Event (default).
Option [2] ON = PGM will deactivate according to the PGM Timer.
4.2.5 PGM Base Time
SECTION [011] Option [3]
Option [3] OFF = PGM Base Time is 1 second (default).
Option [3] ON = PGM Base Time is 1 minute.
4.2.6 PGM Timer
SECTION [013]
To program the timer, enter a 3-digit decimal value (001 to 255) in section
[013].
4.2.7 PGM Test
SECTION [030]
Use this section to initiate a PGM test, which will activate the PGM for 8
seconds. Enter section [030] to activate this test.
Event group Feature group Start # End #
PGM [014] [015] [016] [017]
Event group Feature group Start # End #
PGM [018] [019] [020] [021]
