20
Appendix A : Specifications
6-1. General Specifications
(1) Printing Method Direct line thermal printing.
(2) Print speed 200mm/sec.
(3) Dot density
180 DPI (Hor / Ver) 180 / 180 (0.142mm / 0.142mm dot)
(4) Printing Width
180 DPI Max 72mm (512 dots)
(5) Number of print columns.
No. of columns
Font “A” Font “B”
180 DPI 42 56
(6) Roll paper Refer to chapter 2 for details on the recommended roll Paper.
Paper width : 50mm~82.5mm
Roll diameter : Max. Ø83mm
(7) Weight 3.75 lbs (1.7Kg)
6. Specifications
