2)VOLTAGE PROTECTION: trips in the event of a short-circuit or
overload, limiting the output current.
3)CIRCUIT DAMAGE PROTECTION: in the events of damage, limit the
damage to extend, minish the loss.
Some protection situations require the amplifier to be switched off and
then back on for normal operating conditions be restored.
i
4. LIMIT LEDS
Amplifier £¢status indicators: these LEDs are able indicating the
operation of the internal limiter, when inserted, or the clipping of the
amplifier. They are POST-LEVEL: in other words they display the status of
"
5. SIGNAL LEDs
Signal status indicators: able to indicate a signal presence in the inputs
of the amplifier.
""
6. BRIDGE LEDS (only for DP1400 and DP4800)
Bridge switch with yellow indication. Pull the switch to the position
RIDGE , it lights up; Pull the switch to the position STEREO , it lights
off.
"B " " "
The bridge position:
5
