Threshold: -20dBu to 14.3dBu, step 0.5dBu
Ratio: 1:1 to 16:1, step 2:1
(8) Linking channel L and R of main output:
Yes / No
Bandwidth: 0.011 to 3.595
(3) Low-cut and High-cut filters of main output (channel L and
R can be adjusted separately):
Frequency of Low-cut filter: 19.7Hz – 202Hz
Frequency of High-cut filter: 12100Hz - 20200Hz
Roll-off of filters: 12dB, 18dB, 24dB, 36dB
Type of filters: Bessel, Butterworth, Linkwitz-Riley
(4) Volume of main output matrixes (channel L and R can be
adjusted separately):
Volume of music: Mute, or -30dB to 0dB, step 0.5dB
Volume of direct sound: Mute, or -30dB to 0dB, step 0.5dB
Volume of echo: Mute, or -30dB to 0dB, step 0.5dB
Volume of reverb: Mute, or -30dB to 0dB, step 0.5dB
(5) Phase inverter of main output (channel L and R can be
adjusted separately):
0°/ 180°
(6) Delay of main output (channel L and R can be adjusted
separately):
On / Off,
0.0mS to 7mS, step 0.1mS
(7) Compressor of main output (channel L and R can be
adjusted separately):
Off / Hard-knee / Soft-knee typeⅠ / Soft-knee type Ⅱ / Soft-
knee type Ⅲ / Soft-knee type Ⅳ / Soft-knee type Ⅴ
1 . Switch to a different page of the center menu by continuous
press [C/S.W].
2 . Rotary knob [MUS VOL/EDIT] adjust the parameters, some
parameters can be rough adjusted by rotating the knob [EFF
VOL/Par. Coarse]
3 .Key[ ]and[ ] switch with a page of the cursor position, adjust
other parameters (or with knob [MIC VOL/Cursor] for quickly
adjusted the cursor position).
4. Center output parameters as follows:
(1) Center output volume:
Mute, or -30dB to +6dB, step 0.5dB
(2) Center output equalizer (10 bands):
Type: PEQ/ Low-shelf / High-shelf
Frequency: 19.7Hz to 20200Hz
Gain: -15dB to +12dB, step 0.1dB
Bandwidth: 0.011 to 3.595
(3) Low-cut and High-cut filters of center output:
Frequency of Low-cut filter: 19.7Hz – 303Hz
Frequency of High-cut filter: 2520Hz – 20200Hz
Roll-off of filters: 12dB, 18dB, 24dB, 36dB
Type of filters: Bessel, Butterworth, Linkwitz-Riley
(4) Volume of center output matrixes:
Volume of music: Mute, or -30dB to 0dB, step 0.5dB
Volume of direct sound: Mute, or -30dB to 0dB, step 0.5dB
Volume of echo: Mute, or -30dB to 0dB, step 0.5dB
Volume of reverb: Mute, or -30dB to 0dB, step 0.5dB
(5) Phase inverter of center output: 0°/ 180°
(6) Delay of center output:
On / Off,
0.0mS to 21mS, step 0.1mS
(7) Compressor of center output:
Off / Hard-knee / Soft-knee typeⅠ / Soft-knee type Ⅱ /
Soft-knee type Ⅲ / Soft-knee type Ⅳ / Soft-knee type Ⅴ
Threshold: -20dBu to 14.3dBu, step 0.5dBu
Ratio: 1:1 to 16:1, step 2:1
Center menuoutput
Subwoofer menuoutput
Threshold: -40dBu to 0dBu, step 0.5dBu
Off / Hard-knee / Soft-knee typeⅠ / Soft-knee type Ⅱ / Soft-
knee type Ⅲ / Soft-knee type Ⅳ / Soft-knee type Ⅴ
Ratio: 1:1 to 16:1, step 2:1
(7) Noise gate of microphone (group A and B can be adjust
separately):Off, or -90dB to 42dB, step 1dB
(8) Linking group A and B microphone:Yes / No
(9) Feedback inhibition of microphone: off ,5 grads, level 1 to 5
Effect menu
1 . Switch to a different page of the effect menu by continuous
press [Effect].
2 . Rotary knob [MUS VOL/EDIT] adjust the parameters, some
parameters can be rough adjusted by rotating the knob [EFF
VOL/Par. Coarse]
3 . Key[ ]and[ ] switch with a page of the cursor position, adjust
other parameters (or with knob [MIC VOL/Cursor] for quickly
adjusted the cursor position).
4. Echo parameters as follows:
(1) Echo volume: Mute, or -30dB to 0dB, step 0.5dB
(2) Phase inverter: 0°/ 180°
(3) Echo mode: mono echo / stereo echo / dual echo
(4) Echo to Reverb: On / Off
(5) Delay time of ECHO 1: 100ms to 600ms, step 5ms
(6) Depth of ECHO 1: 0% to 100%, step 1%
(7) Pre-delay of ECHO 1: 0ms to 200ms, step 1ms
(8) Delay time of ECHO 2: 100ms to 600ms, step 5ms
(9) Depth of ECHO 2: 0% to 100%, step 1%
(10) Pre-delay of ECHO 2: 0ms to 200ms, step 1ms
(11) Echo equalizer (10 bands):
Type: PEQ/ Low-shelf / High-shelf
Frequency: 19.7Hz to 20200Hz
Gain: -15dB to +12dB, step 0.1dB
Bandwidth: 0.011 to 3.595
(12) Low-cut and High-cut filters of Echo:
Frequency of Low-cut filter: 19.7Hz – 1000Hz
Frequency of High-cut filter: 8000Hz - 20200Hz
Roll-off of filters: 12dB, 18dB, 24dB, 36dB
Type of filters: Bessel, Butterworth, Linkwitz-Riley
5. Reverb parameters as follows:
(1) Reverb volume: Mute, or -30dB to 0dB, step 0.5dB
(2) Phase inverter: 0°/ 180°
(3) Type of reverb: Off/ Room / Small Hall / Hall / church
/Cathedral/Vocal
(4) Pre-delay of Reverb: 0ms to 250ms, step 10ms
(5) Reverb time: 0.5s to 6s, step 0.1s
(6) Reverb equalizer (10 bands):
Type: PEQ/ Low-shelf / High-shelf
Frequency: 19.7Hz to 20200Hz
Gain: -15dB to +12dB, step 0.1dB
Bandwidth: 0.011 to 3.595
(7) Low-cut and High-cut filters of Reverb:
Frequency of Low-cut filter: 19.7Hz – 1000Hz
Frequency of High-cut filter: 8000Hz - 20200Hz
Roll-off of filters: 12dB, 18dB, 24dB, 36dB
Type of filters: Bessel, Butterworth, Linkwitz-Riley
6. Effect parameters as follows:
(1) Effect volume: Mute, or -30dB to +6dB, step 0.5dB
Main output menu
1 . Switch to a different page of the main output menu by
continuous press [Main].
2 . Rotary knob [MUS VOL/EDIT] adjust the parameters, some
parameters can be rough adjusted by rotating the knob [EFF
VOL/Par. Coarse]
3 . Key[ ]and[ ] switch with a page of the cursor position, adjust
other parameters (or with knob [MIC VOL/Cursor] for quickly
adjusted the cursor position).
4. Main output parameters as follows:
(1) The left and right channel of main output volume:
Mute, or -30dB to +6dB, step 0.5dB
(2) Main output equalizer (10bands, channel L and R can be
adjusted separately):
Type: PEQ/ Low-shelf / High-shelf
Frequency: 19.7Hz to 20200Hz
Gain: -15dB to +12dB, step 0.1dB
4
1 . Switch to a different page of the subwoofer menu by
continuous press [C/S.W].
2 . Rotary knob [MUS VOL/EDIT] adjust the parameters, some
parameters can be rough adjusted by rotating the knob [EFF
VOL/Par. Coarse]
3 . Key[ ]and[ ] switch with a page of the cursor position, adjust
other parameters (or with knob [MIC VOL/Cursor] for quickly
adjusted the cursor position).
4. Subwoofer output parameters as follows:
(1) Subwoofer output volume:
Mute, -30dB to +10dB, step 0.5dB
