23
Green level for
selected colour
temperature
0xb5,
nn | “+” | “-” |
“r” | “R” |
“?”
Set the level of the green
channel for the selected colour
temp. =
value/increment/decrement
Reset
Query
Green level for selected colour
temperature.
Range : “8””0”-“F””F”
Default : “F””F”
Blue level for
selected colour
temperature
0xb6,
nn | “+” | “-” |
“r” | “R” |
“?”
Set the level of the blue channel
for the selected colour temp. =
value/increment/decrement
Reset
Query
Blue level for selected colour
temperature.
Range : “8””0”-“F””F”
Default : “F””F”
Backlight
Brightness control
0xe0
nn | “+” | “-” |
“r” | “R” |
“?”
Set brightness =
value/increment/decrement
Reset
Query
Set backlight brightness
Range : “0””0”-“F””F”
Default : “F””F”
e.g “1””0”  0xe0 0x31 0x30
* Need to short JP2 to 3-4 closed
for enabling the backlight
brightness control.
* Apply for inverter control
voltage in range of 0~5V.
Each step interval is in 1
Backlight on/off
control
0xe1,
“0” |
“1” |
“r” | “R” |
“?”
Set backlight brightness =
Disable backlight
Enable backlight
Reset (Default = Backlight on)
Query
Backlight on/off.
Other control
Function Command Description Acknowledge (if enabled)
Select RS-232
acknowledge
0xc1, “0” | “1” Disable/enable command
acknowledge.
“0” – acknowledge disabled.
“1” – acknowledge enabled.
Auto-setup 0xc3 Start auto-setup of current
vmode.
“0” – fail.
“1” – successful.
Auto RGB
Calibration
0xc5 Start auto-calibration of gain of
the RGB amplifier.
“0” – fail.
“1” – successful.
Load factory
defaults
0xce Reset all parameters to default
value
“1” – successful.
