Specifications:
Frequency: CH1: 525.1MHz
CH2: 645.9MHz
Transmission Range: 60m
Microphone Power: 2 x AA per Microphone
Pick up: Dynamic
Dimensions: Microphone: 240(L) x 50(Dia.) mm
Receiver: 210(L) x 140(D) x 42(H) mm
Flyout:
1.
Antenna
2.
Mix Out
3.
Power Input
4.
Balance Output
5.
Power Button
6.
Volume Control
7.
LED Indicators
8.
Power Switch
