To assign an effect to the Expression Pedal for control and set the Min/Max values:

1. Any effect you wish to assign to the Expression Pedal must be turned on before it can be

assigned. For information on turning an effect on, see "Turning Effects On & Off" on page

16.

2. From Play Mode, press the right arrow EDIT button repeatedly until the EXP (Expression)

LED is lit. An effect LED will also light indicating which effect the Expression Pedal is currently

assigned to and the LED display will show which effect control the Expression Pedal is

currently assigned to.

3. Turn the SELECT knob to select the effect control you wish to control (see the table on the

previous page for a list of effects selectable for control). As you turn the

SELECT knob the

effect’s LED associated with the effect control will light.

4. Once you've selected the effect you want to control, press the right arrow EDIT button

once. You have now selected the Minimum (pedal toe up) control range. Turn the

SELECT

knob to set this to the value which you want the Expression Pedal's full toe up position to

represent (the lowest value selectable by the Expression Pedal).

5. Press the right arrow EDIT button once. You have now selected the Maximum (pedal toe

down) control range. Turn the

SELECT knob to set this to the value which you want the

Expression Pedal's full toe down position to represent (the highest value selectable by the

Expression Pedal).

6. Store the changes to a preset for later recall. See "Storing/Copying Presets" on page 17 for

further information.
