Hot Rod Distortion
Owners Manual 18-1803V-A
Please visit DigiTech
on the World Wide Web at:
www.digitech.com
Printed of China
SPECIFICATIONS:
• Controls - Level, Gain,Tone, Morph,
On/Off Pedal
• Jacks - Input, Out 1 (Amp), Out 2
(Mixer)
• Input Impedance - 1 MOhms
• Output Impedance - 100 Ohms
• Power Supply - 9V Alkaline Dry Battery
• Power Consumption - 4.8Watts
(w/optional PS200R power supply)
• Battery Life - Approximately 4 hours
(with continuous usage)
• Dimensions - 4 15/16”(L) x 3 1/8”(W)
x 2 1/8”(H)
• Weight - 1.38 lbs.
• Optional Power Supply
PS200R - 100 (100V ~ 50/60Hz)
PS200R - 120 (120V ~ 60Hz)
PS200R - 230 (230V ~ 50Hz)
PS200R - 240 (240V ~ 50Hz)
