1.4 OnyxWorks Interface
The serial data from the OnyxWorks contains a variety of signals. The PrismLX will only
act on two signals. The two signals are noted below:
This signal is for the activation of a Fire Alarm.
This signal is for the Restoral of a Fire Alarm.
The Prism LX only acts on the Description: field and the Status: field, however the
structure of the OnyxWorks string must be as noted in its entirety.
****************************** <CR><LF>
Actual Time: 3/19/2020 11:01:49 AM <CR><LF>
Network: Columbus Place <CR><LF>
Node: Gains. Garage <CR><LF>
Point: 0328 FA GAINSBOR0UG <CR><LF>
Point Type: Track Supervisory <CR><LF>
Description: 0328 FA GAINSBOR0UG (total of 35 Characters) 12345<CR><LF>
Status: Supervisory Alarm <CR><LF>
Action: <CR><LF><CR><LF>
******************************<CR><LF>
Actual Time: 3/19/2020 11:04:24 AM<CR><LF>
Network: Columbus Place<CR><LF>
Node: Gains. Garage<CR><LF>
Point: 0328 FA GAINSBOR0UG<CR><LF>
Point Type: Track Supervisory<CR><LF>
Description: 0328 FA GAINSBOR0UG (total of 35 Characters)12345<CR><LF>
Status: Supervisory Normal<CR><LF>
Action: <CR><LF><CR><LF>
Figure 1-1, Fire Alarm Activation Signal
Figure 1-2, Alarm Restoral Signal
