Introduction Digitize Inc
700300-0001 Rev. B 10/21 1-3
1.5 Description Field
The Description field must contain a four-digit number that represents the Telegraph Box
number to be queued up to be transmitted or aborted. If the box number only has one,
two or three digits, they must be preceded by zeroes. The box number must be followed
by the Letters FA. The FA is can be followed by up to 35 Alpha numeric characters
representing the building or address of the Fire Alarm.
There must be a space character separating the various items used to produce the proper
event. A letter ‘b’ will be used to illustrate the required space as follows:
Description:b328bFAbGAINSBOR0UG…
The total number of characters for the “Description:” location of the Fire Alarm and
Restore event can be up to 35 characters Including the “GAINSBOROUG” as noted.
GAINSBOR0UG (total of 35 Characters) 12345<CR><LF>
1.6 Status Field
The Status field must contain either the words ‘Supervisory Alarm’ or ‘Supervisory
Normal’ in combination with the Description field information to produce a Fire Alarm
or Alarm Restoral.
1.7 Restoral signal
The OnyxWorks Fire Alarm signal must eventually be followed by a Restoral signal in
order to be removed from the PrismLX (and Remote Annunciator) display.
