© 2017 Digitrax, Inc. www.digitrax.com15
15
Sound Meaning
Continuous short
beeps
In Voltage Trim Mode, selection is in range.
1 Short Beep During operation, DB210/DB220 has recovered from a fault
2 Short Beeps Initial DB210/DB220 Power on
4 short Beeps Booster short circuit shutdown.
4 Long Beeps Input Voltage is out of the range 13.8V to 24V DC
DB210/DB220 AUDIBLE SOUNDS
6.0 DB210/DB220 Indication Lights
The DB210/DB220 uses dierent combinations of the available indicators to
provide information. The indicators can show what mode the DB210/DB220 is
in as well as indicate errors and operations.
Indications Meaning
PWR RED winking off every 3
seconds as a “Heartbeat”
The DB210/DB220 is powered on, Normal Operation Mode.
PWR off blinking on RED every
4 seconds
The DB210/DB220 is in SLEEP mode.
PWR flashing RED, all other
indicators off
Input Voltage out of Range 13.8V to 24V DC.
PWR flashing GREEN DB210/DB220 Internal fuse blown, replace fuse.
PWR RED winking off 2 times
every 4 seconds
The DB210/DB220 is in Safe Operation Mode. Check your
power supply to make sure it is appropriate for your track
voltage settings.
PWR flashing GREEN simulta-
neously with NET flashing RED
The DB210/DB220 is in Options Switch Mode.
PWR flashing alternating
GREEN/RED once a second
The DB210/DB220 is overheated and has shutdown.
PWR flashing Green alternating
with NET flashing RED slow,
about once a second
The DB210/DB220 is updating IPL firmware Via LocoNet.
TRACK STATUS is lit Indicates there is power to the track. This indicator will be
GREEN or different shades of Yellow/Orange depending on
Zero Stretching.
NET indicator Solid RED on LocoNet OK.
NET indicator Solid on RED,
wink off
DB210/DB220 detects a valid LocoNet message.
NET indicator off DB210/DB220 detects a low voltage on LocoNet.
DB210/DB220 INDICATION LIGHTS
