Back Panel:
1. AC input
2. Output receptacles
3. USB & RJ11 (optional)
4. USB & RS232 (optional)
5. RJ45 (optional)
6. Circuit breaker
1. Inspection
Remove the UPS from its packaging and inspect it for damage that
may have occurred during shipping. If any damage is discovered,
repack the unit and return it to the place of purchase.
2. Charging
This unit is shipped from the factory with its internal battery fully
charged. However, some charge may be lost during shipping and the
battery should be recharged prior use. Turn on the UPS, plug the unit
into an appropriate power supply and allow the UPS to charge fully by
leaving it plugged in for at least 6 hours with no load (no electrical
devices such as computers, monitors, etc.) connected.
6 hours
DN-170066/ -75/ -76
DN-170065/ -74
DN-170063/-64
1000 VA
