6
Figure 1: Extract the UPS front cover
A small amount of arcing may occur when connecting the internal
batteries. This is normal and will not harm personnel. Connect the cables
quickly and firmly.
b) Connect the internal battery connector (see Figure 2). Connect red to red,
Press the connector tightly together to ensure a proper connection.
Figure 2: Connecting the UPS internal batteries
c) Replace the UPS front cover
To replace the cover, verify that the ribbon cable is protected.
Put the front cover hooks of side with display to the cover port, put
another side to the other two ports, then press it until the cover and the
chassis are combined tightly.
