Digitus DN-60021-2 User Manual

Specifications
Model DN-60011-2 DN-60021-2
Description
16 Port Fast Ethernet
Switch
24 Port Fast Ethernet
Switch
Standard IEEE802.3, IEEE802.3u, IEEE802.3az, IEEE802.3x
Network Media
10BASE-T: UTP category 3,4,5 cable (≤100m)
100BASE-TX: UTP category 5 cable (≤100m)
MAC Address Table 8K, Auto-learning, Auto-aging
Transfer mode Store-and-Forward
Frame Forward Rate
10Base-T: 14881pps/Port
100Base-TX: 148810pps/Port
Switching Capacity 3.2Gbps 4.8Gbps
Forwarding Rate 2.4Mpps 3.6Mpps
Packet buffer 2M bit
Dimensions (L*W*H) 280 *179 *44 mm
Fan Fanless
Power Input AC: 100~240V, 50/60Hz
Temperature
Operating Temperature: 0°C ~ 40 °C (32 °F ~104°F)
Storage Temperature: -40 °C ~ 70 °C (-40 °F ~158°F)
Humidity
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Green energy saving IEEE 802.3az
MTBF >50000 hours

Digitus DN-60021-2 Specifications

General

Brand	Digitus
Model	DN-60021-2
Category	Network Router
Language	English
