Digitus DS-12890 User Manual

6
Back Panel
9) Output ports:
Connect to a mouse or a keyboard.
Connect to a keyboard or a mouse.
Connect to an amplifier.
Connect to a MIC.
Connect “HDMI Out” to HDMI display.
Connect “DisplayPort Out” to DP display.
10) PC1 input ports:
Respectively connect to DisplayPort, USB, MIC, stereo ports of PC1.
11) PC2 input ports:
Respectively connect to DisplayPort, USB, MIC, stereo ports of PC2.
12) PC3 input ports:
Respectively connect to DisplayPort, USB, MIC, stereo ports of PC3.
13) PC4 input ports:
Respectively connect to DisplayPort, USB, MIC, stereo ports of PC4.
14) DC 5V: Plug the 5V DC power supply into the unit.
