6
No.
Name
Function Description
1
IR
IR receive window
2
Power LED
The red LED illuminates when the
device is working or on standby.
3
OUT 1
Button:
Short press to switch the input
selected by OUT 1;
Long press for 3s to turn on/off the
downscaler corresponding to OUT 1.
LED:
When switching to the corresponding
input source, the
corresponding input LED illuminates
green;
Otherwise, the LED will not light up.
4
OUT 2
Button:
Short press to switch the input
selected by OUT 2; Long press for 3s
to turn on/off the downscaler
corresponding to OUT 2.
LED:
When switching to the corresponding
input source, the
corresponding input LED illuminates
green; Otherwise, the LED will not
light up.
