7
5
OUT 3
Button:
Short press to switch the input
selected by OUT 3; Long press for 3s
to turn on/off the downscaler
corresponding to OUT 3.
LED:
When switching to the corresponding
input source, the corresponding input
LED illuminates green; Otherwise, the
LED will not light up.
6
OUT 4
Button:
Short press to switch the input
selected by OUT 4; Long press for 3s
to turn on/off the downscaler
corresponding to OUT 4.
LED:
When switching to the corresponding
input source, the corresponding input
LED illuminates green; Otherwise, the
LED will not light up.
7
SERVICE
Connect to PC via Micro to USB cable
for firmware upgrade.
