Dilo SF6-LeakPointer - Page 6

SF
6
-LeakPointer | 3-033-R002
www.dilo-gmbh.com | C 3970-00 | Page 6 / 12
Dimensions with case:
Length (L): 300 mm / 11.8”
Width (B): 230 mm / 9.1 “
Height (H): 75 mm / 3”
Weight with case and accessories: 1.2 kg / 2lbs. 9 oz.
Dimensions of the probe:
(metal flex)
Length (L): 365 mm / 14”
Diameter: 6.4 mm / 0.25”
General data:
Sensor: State of the art Cold Cathode Discharge Diode
Response time T90: approx. 1s
Recovery time: approx. 1s
Ambient moisture: up to 90% relative moisture, non-condensing during
operation
Operating temperature: -20° - +50 °C / -4 to 122 °F
Sensitivity: Fully automatic sensitivity selection with 6 visible LED
range indicators. Maximum sensitivity allows
detection of approx. 5 g/yr.
Audible alarms: Two user selectable audible alarm options (High and
low intensity alarm tones)
