-LeakPointer | 3-033-R002
www.dilo-gmbh.com | C 3970-00 | Page 7 / 12
Visual alarms: TACHOMETER bar graph display. Eight high
intensity LEDs are arranged in a Tachometer-like
display indicating leak intensity per sensitivity range.
GEARSHIFT display is arranged in a gearshift
pattern. Seven LEDs indicate the current sensitivity
range of the unit and subsequent leak size as follows:
GEAR --- LEAK SIZE
N --- No Leak
1 & 2 --- Small
3 & 4 --- Medium
5 & 6 --- Large
Power: Three size ‘C’ alkaline batteries (NEDA/ANSI 14A)
Continuous Operating battery life at 25 °C (77°F):
High intensity alarm: 55 hrs
Low intensity alarm: 75 hrs
Because the instrument turns itself off after 10 min. of
inactivity, the actual useful battery life may be longer
than stated. See Maintenance section for LO BAT
conditions.
2.2 Standard accessories
1 Carrier case
3 1.5 V alkaline batteries
1 Spare sensor
1 Operating manual (multilingual) on CD-ROM
