Dimplex CDE2TI Cadiz Eco User Manual

Thermostat (CDE2TI(B) models only)
The Thermostat (see ‘T’ in Fig. 3) controls the heat output according
to the room temperature. This ensures that the heater will not produce
heat unnecessarily when the room is warm. To set the temperature you
require, turn the thermostat knob clockwise until the required setting is
reached. Alternatively to heat a cold room quickly, turn the thermostat
knob up fully. When the room has reached the desired temperature, turn
the thermostat knob anti-clockwise until the thermostat just clicks off. The
heater will now automatically operate at this temperature. The thermostat
also has a frost protection setting marked ‘ ’. This setting is useful in
areas such as garages, to prevent frost damage. If the thermostat is set
to its minimum setting ‘ ’, the heater will cycle on and off to maintain
a temperature of approximately 5° to help protect against frost.
Note: Should the heater fail to come on when the thermostat is at a low
setting, this may be due to the room temperature being higher than the
thermostat setting.
Heat Selector Switches (CDE2TI(B) models only)
Mono and Dual Panel Heat Settings
Selector switches located on the control panel provide a choice of Half
Heat or Full Heat output to suit varying conditions and for economy of
operation.
Half Heat Setting - left hand side - This switch as shown in
Fig. 3 provides half heat output when activated. When it is activated a
neon light ‘x’ illuminates below the control button and the left hand side
element turns on.
Half Heat Setting - right hand side - This switch as shown in
Fig. 3 provides a half heat output when activated. When it is activated
a neon light ‘x’ illuminates below the control button and the right hand
side element turns on.
High Heat Setting - With both switches activated (see Fig. 3)
the maximum output of the heater can be achieved. When both switches
are activated neon lights ‘x’ below each control button illuminate.
Note: The heater will only operate when the On/Off button is activated.
Digital Timer Operation (see ‘z’ in Fig. 3 & Fig. 4)
(CDE2TI(B) models only)
IMPORTANT: Remember to observe all safety warnings when operating
the heater on auto setting, either attended or unattended.
The timer allows you to select ‘AUTO’ or ‘MAN ON’ by pressing the
‘MODE’ button until the required MODE appears at the bottom of the
timer display.
‘MAN OFF’ MODE heat is permanently off. This is also the default screen.
‘MAN ON’ MODE allows power to the heater uninterrupted by the
program settings.
‘AUTO DLY’ switches the heater ON and OFF every day according to
a set daily program.
‘AUTO BLK’ switches the heater ON and OFF according to a set of
programs for weekdays only or weekends only.
Key Lock:
If ‘ENTER’ and ‘MODE’ are pressed within 1 second, the keys will be
locked. The user will know the keys are locked as the lock symbol ‘ ’
will be displayed on the top left hand corner of the screen. To unlock the
keypad, press ‘ENTER’ and then ‘MODE’ within 1 second.
Initial Operation
For initial use, plug the heater into a regular household power point and
turn the power on. The timer is now ready to be set up for use.
Setting Current Time
1. Hold the ‘PROGRAM’ button until the clock symbol appears on the
screen. The user can now set the clock.
2. The hour digit will ash. To adjust the hour use the ‘-’ & ‘+’ buttons.
Conrm the hour digit by pressing ‘ENTER’.
3. Once ‘ENTER’ has been pressed the minutes will ash. To adjust the
minutes use the ‘-’ & ‘+’ buttons. Conrm the minute digit by pressing
‘ENTER’.
4. The timer now returns to the default display.
Once the correct time is set, a total of four ON/OFF time programs can
be set for operation.
Setting Programmes
OPTION 1; Daily (‘DLY’ on display): This is a daily program function,
Monday to Sunday with four ON/OFF program options available.
OPTION 2; Block (‘BLK’ on display): This is a block program function,
Monday to Friday with four ON/OFF program options or Saturday to
Sunday with four ON/OFF program options.
Press the ‘PROGRAM’ key to set the programs starting with ‘Daily
ON’ P1.
SETTING P1 ON TIME:
1. To set the hour use the ‘-’ & ‘+’ buttons. Conrm the hour digit by
pressing ‘ENTER’.
2. To set the minutes use the ‘-’ & ‘+’ buttons. Conrm the minute digit
by pressing ‘ENTER’.
Note: The minutes can only be set in 10 minute blocks in programme
‘MODE’.
SETTING P1 OFF TIME:
3. To set the hour use the ‘-’ & ‘+’ buttons. Conrm the hour digit by
pressing ‘ENTER’.
4. To set the minutes use the ‘-’ & ‘+’ buttons. Conrm the minute digit
by pressing ‘ENTER’.
Repeat steps 1 to 4 to programme P2, P3 & P4. After programming P4
‘OFF’ you automatically exit to the default display.
At any time while programming the timer you can press the ‘PROGRAM’
button to exit to the default display.
Note: If the ‘ON’ time is the same as the ‘OFF’ time the appliance will
ignore the program.
The Advance Function
When in ‘AUTO’ MODE, if the ‘+’ button is pressed for longer than 2
seconds the programme will ADVANCE to the next setting programmed
and will only revert back to the program when the subsequent programme
time is reached. When the ‘ADVANCE’ function is running the ‘ADVANCE’
segment will be displayed on the LCD screen. If the ‘-’ button is pressed
when the ‘ADVANCE’ programme is running the ‘ADVANCE’ feature
will be automatically cancelled and the programme will run as normal.
Note: Timer Memory Back Up Batteries - Once the heater has been left
plugged in with the socket switched on for at least 72 hours the timer’s
memory back up batteries will be fully charged.
Once the timer batteries are fully charged, if there is a power cut or if
the heater is disconnected from the mains for less than six months,
then the timer will continue to keep time & the settings in the memory
will remain intact.
If however the timer back up batteries have not been charged fully,
or if the heater is deprived of power for longer than six months, then
the time and the programme settings are likely to be lost and you may
therefore need to reset the time and the programme before using the
AUTO MODE again.
Electronic Climate Control - see Fig. 2
(CDE2ECC(B) & CDE24ECC(B) models only)
Operation
The electronic control allows MANUAL and AUTO operation.
In MANUAL ON mode there are three heat settings:
L/H Side Heat, R/H Side Heat and High Heat
In AUTO mode the heater comes on as per the programmed timer
settings (see Setting programs). At any point if the heater is active i.e.
heat is being produced, the ‘ ’ neon is lit - see Fig. 2.
Initial Operation
When the heater is connected to the mains the ‘ ’ neon will be lit and
the display is blank. Press the ‘ ’ button and the display goes to full
heat set to 35
o
C - see Fig. 7.
Note: All display characters are displayed in Fig. 12.
Standby Mode
With the heater ON if the ‘ ’ button is pressed, the heater will go into
standby mode, heater switches off, the display goes blank and only the
MAINS ON neon ( ) remains lit. On pressing the ‘ ’ button again the
heater will come on in the mode and with the settings it had prior to
going into standby mode.
Setting Time
1. Press and hold ‘ ’ and the clock symbol ‘ ’ appears on the top left
hand side of the screen. The user can now set the time.
2. The hour digit will ash. To adjust the hour use the ‘ ’ & ‘ ’ buttons.
Conrm the hour digit by pressing ‘ ’.
3. The minute digit will ash. To adjust the minute use the ‘ ’ & ‘ ’
buttons. Conrm the hour digit by pressing ‘ ’. The display
will return to the state before entering set time.
N.B. If no keys are pressed after 4 minutes the display will revert to the
state prior to entering set time.
