Heater Installation
CAUTION:
Ensure the wire connectors are securely tightened, so
no bare wires (live or neutral) are exposed.
Connect the 2 pin connector to the 2 pin connector from the Opti-myst
cassette heater control wire harness.
WARNING: Disconnect power before attempting any maintenance
or cleaning to reduce the risk of re, electric shock or damage to
persons.
G N L
HEATER PIG
TAIL LEADS
CASSETTE PIG
TAIL LEADS
POWER SUPPLY
CABLE LEADS
HEATER
CASSETTE
Figure 6
