Heater Installation
handle.
Slide spacer over the carriage 3.
bolt shaft and insert in
hanger bracket opening and
hold them in position.
Slide lock washer and thread 4.
on T-Handle onto carriage
bolt, turning to tighten.
Hanger Bracket Mounting Options
Air In
Air Out
Hanger
Bracket
Carriage
Bolt
Spacer
Lock Washer
T-Handle
Figure 3
