Status LED Blinking Pattern Details
Mains detected OK
Green LED ON
Mains restarting
Green LED ON for 3 seconds,
flashes off for 0.5 seconds
Link status establ ished
Link status re-establishing
connection
Link status not established -
default at power ON
Link status connection lost
ON
OFF
ON ON ON ON
OFF OFF OFF
ON ON ON ON
OFF OFF OFF
ON ON ON ON
OFF OFF OFF
ON ON ON ON
OFF OFF OFF
Red LED ON
Green LED ON for 3 seconds,
flashes off for 0.5 seconds
Amber LED ON for 3 seconds,
flashes off for 0.5 seconds
Red LED ON for 3 seconds,
flashes off for 0.5 seconds
STATUS
MA
INS
The STATUS LED has
three available colours:
Red
Green
Amb
er
The MAINS LED is green.
The blinking patterns of the
lights indicate the device
status (s
ee table).
Pairing Button
