Dimplex GDH-DEH16E User Manual

1. Prepare PVC hose to drain out water
(The hose requires an inner dia of 13mm)
2. Take out the bung of the drainage outlet .
3. Take out the soft cover, put it and tube bung
into the bucket for storage.
4. Connect the PVC hose with the drainage outlet.
5.Place the bucket in its original location.
For drainage
Back of the unit
Bucket
Push bucket back into
the unit toward the direction
as the arrow points to
Drainage PVC hose
Drainage PVC hose
Tube stopple
Tube stopple
Soft cover
Continuous Drainage Feature
The Proper Way To Place The Water Drainage PVC Hose
1)
Put the PVC hose into the back of the closed hole, then connect the PVC hose
to the front.
When using continuous drainage, the PVC hose most be placed below the drainage
hole.
CONTINUOUS DRAINAGE
C
ontinuous drainage outlet
PVC hose is not sold with this unit.
, but is readily available from your local hardware store.
