Dimplex LC Series User Manual

www.dimplex.com2
Warranty
The Manufacturer warrants the linear convector and components of the
enclosed product against any defect in material or workmanship for a period
of one year from the date of purchase, with the exception of the elements
which are warranted to be free from defect in material and workmanship
for ten years. In full satisfaction of any claims under this Warranty the
Manufacturer will repair or replace without charge, in its factory or in the eld
as it alone may decide, any parts which in its opinion are defective.
The Manufacturer shall not be responsible for any transportation or shipping
costs in relation to such repair or replacement except as specically
assumed by it. Misuse of this product or repairs by persons other than the
Manufacturer’s authorized personnel without the Manufacturer’s written
approval, will void this Warranty.
This Warranty is in lieu of all other warranties or conditions whether
expressed or implied including but not limited to those of merchantability or
tness for purpose and shall constitute the sole remedy of the Purchaser
and the sole liability of the Manufacturer in respect of the sale of the product,
whether in the nature of breach or breach of fundamental term, or of
negligence or otherwise.
The Manufacturer shall not be liable for any special, indirect or consequential
damages or for any damages resulting from removal or replacement of
a linear convector subject to warranty claim without the Manufacturer’s
authorization.
This Warranty is transferable by the original consumer purchaser of the
product. Any claims under this Warranty must be submitted in writing to
the Service Manager, Dimplex North America Ltd., 1367 Industrial Rd.,
Cambridge, Ontario N1R 7G8, Canada.
CAUTION: Before removing the front cover for cleaning, make
certain the power has been turned off at the circuit breaker
panel.
CAUTION: Allow adequate time for the element and body
casing to cool before attempting to work on the linear convector.
The LC series contain no moving parts. Since the appliance
contains no moving parts little maintenance is required beyond
vacuum cleaning. It is however essential that the linear
convector is not operated with an accumulation of dust or dirt on
the element, as this can cause a build up of heat and eventual
damage. For this reason the linear convector must be inspected
regularly, depending upon conditions and at least at yearly
intervals. Once cleaning is complete replace the front cover and
restore power.
WARNING: The user can perform cleaning ONLY. All other
servicing should be performed by qualied service personnel.
Maintenance
This linear convector must be properly installed before it is used.1.
Prior to energization remove all construction dirt (plaster, 2.
sawdust, etc.) from interior and exterior of linear convector.
Dimplex linear convectors are designed and tested for safe and
trouble-free operation. All Dimplex linear convectors are protected
against overheating by a built-in thermal cutout. Free airow
throughout the linear convector is extremely important for the most
efcient operation of the linear convector. Restricted airow may
cause the thermal overload protector to cycle the linear convector
“ON and OFF”. A cycling linear convector will not supply sufcient
heat to the room.
CAUTION: Avoid direct contact of paper, fabric, or furniture with
linear convector.
Operation
Wire unit as per diagrams on page 6 and National and Local 3.
Electrical Codes.
Position Linear Convector, pushing cable back into wall (or con-4.
duit), run screws through pre-selected mounting holes and spac-
ers (if applicable), using appropriate wall anchors, if necessary.
!
NOTE: Screw should be backed off 1/2 turn from snug posi-
tion to allow free expansion and contraction of housing and to
ensure quiet operation.
Replace covers on unit.5.
!
NOTE: Install the center cover rst, by installing the top rst,
then the bottom.
CONNECTING MULTIPLE LINEAR CONVECTORS TOGETHER
The linear convectors can be connected end to end to form a
continuous length of linear convector section. When units are
installed end to end, join the linear convectors to ensure ground
continuity between.
