Dimplex QM050 Installation Instructions

- 10 -
Building the Heater Core
10. Remove the inner front and insulation to gain
access to the core of the heater.
Lay the inner front carefully to one side to ensure it
is not damaged.
11. Remove the internal packaging.
Fig. 10
Fig. 11
Fig. 10
Fig. 11
