Dingo Tools 52CC - Blade Assembly Options; Blade Type Overview; Handlebar Connection

4
M. EIGHT TOOTH
M. FOURTY TOOTH
M. THREE TOOTH
M. FOUR TOOTH
(please note that quantities of blades will vary per model - 5in1, 6in1, 7in1, 8in1)
(please note that quantities of blades will vary per model.)
M. TWO TOOTH
M. PLASTEC
HOW TO CONNECT HANDLE BARS
BLADE ASSEMBLY
STEP 1
Connect both bars into center bracket.
STEP 2
Attach top bracket and tighten four hex screw
accordingly until fi rm.
