Dini Argeo TPW User Manual

TPW
9
USER_MANUAL_ENG_TPW_4_R1
The raised load is moved forwards or backwards by the tiller, which controls the steering wheels.
Transport
POS. 1 > central
The tiller is completely free for transport manoeuvres.
Lifting
POS. 2 > low
Pull the tiller downwards to start up the lifting pump. A return spring places the tiller back in its upright position.
Lowering
POS. 3 > – high
Pull the lever upwards to lower the load. The descent speed is controlled by a special valve that starts up when the lever is firmly
pulled to the end of its stroke.
The pallet truck is equipped with a dual-function tiller: traction or manoeuvre and hydraulic lift.
NOTE: raise or lower the pallet truck ONLY when stationary.
Truck controls
