5. Product Description
The NRGkick charging unit consists of the charging cable with the vehicle connector, the electronics in a
plastic housing (charging unit) including the residual current protection mechanism, optional energy meter
with Bluetooth interface and the power grid cable with connector.
The charging unit is available in a number of different models:
• Total cable length: 5m or 7.5m
• Vehicle connector acc. to IEC62196 (Type 2) or SAE J1772 (Type 1)
• 1-phase or 3-phase charging mode
• Maximum charging current 16A or 32A
• Energy meter and Bluetooth LE interface
The integrated residual current protection mechanism means NRGkick charges your vehicle in accordance
with the highest safety standards. The mechanism breaks the current reliably if AC or DC residual currents
occur. The charging unit is designed such that it is easy to adjust the charging current via a selection button.
The LED indicator shows you the selected charging current and power at all times. If you have purchased
the “energy meter with Bluetooth LE” product option you can also change the charging current without
interrupting the charging process. In combination with the NRGkick smartphone App, the energy meter
provides additional functions with full transparency and visibility into every charging event.
5.1 Charging Unit – NRGkick
1) Selection button
2) Display: Selectable charging power
3) Display: Selectable maximum charging
current
4) LED indicator:
Selected current or power
5) LED status indicator
6) Information on the maximum possible
charging current that can be set
depending on the requirements of the
different power grid connectors.
The text may vary depending on the specific model!
