Dino-Power DP-X Series - Page 11

Startup
1. First be sure the ON/OFF switch is OFF.
2. Adjust Pressure Control counter clockwise to
lowest pressure.
3. Place the suction hose into the coating barrel.
4. Pull up the Prime/Spray Valve to Prime
position.
5. Plug sprayer in a grounded cable socket.
6. Switch ON the machine
。
7. Turn the Pressure Control clockwise, till the
fluid is circulating in the prime tube
8. Turn power switch OFF.
9. Transfer suction tube to paint pail and
submerge suction tube in
paint.
10.Turn power switch ON.
11. When you see paint coming out of prime
tube:
(1). Point gun into waste pail.
(2). Unlock gun trigger lock.
(3). Pull and hold gun trigger.
(4). Turn Prime/Spray valve to SPRAY position.
12.Continue to trigger gun into waste pail until
you see only paint coming out of gun.
13. Release trigger. Engage trigger lock.
14.Transfer prime tube to paint pail and clip
prime tube to suction tube.
