before triggering the gun on.
7. When taking a short break from painting (up to 1 hr.), lock the spray gun trigger OFF, reduce pressure
to its minimum (zero) setting and set the unit to Prime position . Turn sprayer off and unplug. Refer
to Pressure Relief Procedure.
8. For interior corners, such as on a bookcase or inside a cabinet,
aim the gun toward the center of the corner to spray. By dividing the
spray pattern this way, the edges on both sides are sprayed evenly.
Install Tip & Guard on Spray Gun
1. Engage trigger lock.
2. Verify tip and guard parts are assembled in
order shown.
3. Use tip to align seat
Tip must be pushed in
guard all the way into guard
4. Screw tip and guard assembly on
gun. Tighten retaining nut.
Gasket
Guard
Tip
