X80L PCB Assembly
No.
Serial No.
Description
Qty
No.
Serial No.
Description
Qty
1
X80501
Circuit Board
1
8
X80508
Screw
4
2
X80502
Frame
1
9
X80509
Plastic Cover
1
3
X80503
Transducer
1
10
X80510
Circuit for Digital Pressure
Display
1
4
X80504
Long Screw
1
11
X80511
Wire
1
5
X80505
Power Cord
1
12
X80512
Switch
1
6
X80506
Screw
4
13
X80513
Panel
1
7
X80507
Screw
4
14
X80514
Pressure Regulator
1
