Dino-Power X24 User Manual

1
Cart/ Hose with wrap rack
Carry machine and Stows paint hose. (DP637H)
2
Filter Housing
(Manifold filter inside**)
Manifold filter will reduce the tip clogs and ensure you nice finish.
3
Digital pressure display
(Under the cover)
X20 With Pressure Gauge Only
X24 X28 X32 X42 X45 X51 X80L With digital pressure display
4
Pressure regulator
Adjust the pressure for different applications.
5
Prime/Spray valve.
●In PRIME position (pointing down) directs fluid to prime
tube.
●In SPRAY position (pointing parallel) directs pressurized
fluid to paint hose.
●Automatically relieves pressure system in overpressure
situations
6
Fluid pump
(piston rod&v-packing** inside)
Drains fluid in system during priming and pressure relief.
7
Suction tube
Draws fluid from paint pail into pump. (the tube must be screwed
tightly otherwise air enter inside, so the pressure can’t be reached
your desired high pressure.)
7
Suction hose*
The pics is X51L lower suction type, For X45, it will be the suction
tube, and X20/24/28 will be the suction hose instead.
8
Suction filter
Suction filter reduce the tip clogs and ensure you nice finish.
9
Prime hose
10
Power Plugs
It will be suitable for countries.
11
Wheel
Easy for machine to stand/move on the ground.
12
Airless spray gun
Dispenses fluid.
13
High pressure hose
Transports high-pressure fluid from pump to spray gun.
(The parts marked with ** are easily worn parts.)
