FORWARD FACING
installation instructions
REAR FACING FORWARD FACING
BOOSTER MODE
FORWARD FACING
FORWARD-FACING INSTALLATIONS:
20-65 lbs (9.1-29.5 kg)
NOTE: IF the child is UNDER 40 Lbs install the
Diono Safe Stop by following the instructions on
page 59 before proceeding.
IMPORTANT: The Safe Stop will need to be
removed once the child reaches 40 lbs.
NOTE: IF the child is OVER 40 LBS, go to Step 1
of Installation using a Shoulder/Lap With 5-Point
Harness
IMPORTANT: IF the child is OVER 25 LBS, lower the
adjustable bottom by following the instructions on
page 40.
NOTE: For Forward-Facing installations using a
LAP BELT ONLY with NO Top Tether anchor point
available, you MUST install the Diono Lap Belt
Cushion by following the instructions on page 60
before proceeding; otherwise go to Step 1 below.
Place car seat forward-facing in the vehicle back
seat. IF the child is over 25 lbs, lower the bottom.
