FORWARD FACING
Lift the bottom bar up and over the inside channel
toward the seat bottom to release. Confirm locked.
Make sure LATCH strap or vehicle seat belt is
routed through the forward-facing belt path marked
with the red label and forward-facing illustrations.
Install this car seat tightly in your vehicle. The car
seat should not move at the forward-facing belt
path location by more than 1 in. (2.5 cm) from side
to side, front to back. If using a lap belt only, refer to
your vehicles owners manual for installation advice.
Harness straps MUST be above the top of your
child’s shoulders. The chest clip should be placed at
armpit level.
The American Academy of Pediatrics (AAP) and
NHTSA recommend that children be rear-facing
until the age of 2 or until they reach the maximum
rear-facing height and weight. This car seat can
remain rear-facing up to 50 lbs.
FORWARD FACING
INSTALL USING LATCH: 20-40 lbs (2.3-18 kg)
Do Not Install by this method for a child weighing
more than 40 lbs (18 kg) Reinstall with vehicle belt
for weights between 40-65 lbs (18-29.5 kg).
1. Remove LATCH Strap from Storage Location on
back of seat.
Fold down cover on back of car seat. Locate the
Latch Strap in the belt storage location shown. Push
in on the red buttons on the LATCH connectors and
remove from storage position 1.
