BELT LOCKING CLIP SAFE STOP
WARNING: If your vehicles lap/shoulder seatbelt is
equipped with ELR (Emergency Locking Retractor)
that does not switch to function as an ALR (Automatic
Locking Retractor), you MUST use a locking clip to
secure lap portion of vehicle seat belt. If you have any
questions; please consult your vehicle owner’s manual
or contact the vehicle manufacturer.
1. Remove Lock Clip from Belt Storage Pocket.
2. Route the vehicle seat belt through the proper belt
path and buckle it in. Pull the vehicle seat belt tight.
While pushing down on seat, pinch the two straps
together behind the buckle tongue. Unbuckle the belt
without allowing it to slip.
2. Attach locking clip to lap and shoulder belts as
shown. Rebuckle belt. Check that lap belt does not
move by pulling hard. If belt loosens or lengthens,
repeat procedure.
1
3
2
SAFE STOP:
ONLY for use in Forward-Facing Installations from
20-40 lbs (9.1 - 18kg). DO NOT use Rear-Facing.
1. Look for the Belt Storage Icon on the back of the
seat and fold down the rear Velcro flap. Detach the
Safe Stop and remove it for use.
2. Remove Harness Straps from Metal Plate –
Unzip cover on back of seat, detach harness from
metal plate. Once detached, thread both harness straps
onto the metal hook of the Safe Stop. Connect Left
side of harness first, then follow with the right.
3. Thread bottom of Safe Stop onto the metal hook of
harness adjuster. Check to ensure proper engagement
to the metal plate. Close cover on back of seat, taking
care to ensure the strap is clear from any obstruction.
.
1
