Direct-Lift PP8 Plus - Table of Contents; Important Information

PP8 Plus 2 IN50001 Rev. C 04/30/2008
TABLE OF CONTENTS
• IMPORTANT INFORMATION pg 2
• OWNER / EMPLOYER RESPONSIBILITY pg 3
• LOCKOUT / TAGOUT pg 3
• SAFETY PROCEDURES pg 4
• LIFT SPECIFICATIONS & FLOOR PLAN pg 6
• TOOLS REQUIRED pg 7
• INSTALLATION INSTRUCTIONS pg 7
• CASTER KIT ASSEMBLY / INSTALLATION pg 11
• FOUNDATION & ANCHORING REQUIREMENTS pg 13
• OPERATION INSTRUCTIONS pg 15
• PREVENTIVE MAINTENANCE SCHEDULE pg 17
• TROUBLESHOOTING pg 18
• CABLE INSPECTION GUIDE pg 20
• ILLUSTRATED PARTS LIST pg 26
• WARRANTY POLICY pg 34
IMPORTANT INFORMATION
Four Post Lifts
1. Always inspect the lift for damage and make note of any damage on the bill of
lading.
2. In case of freight damage, call the truck line immediately and report the damage as
a freight claim.
3. IMPORTANT! Make sure you have extra help or heavy duty lifting equipment
when unloading and assembling the lift..
4. Please read the safety procedures and operating instructions in this manual before
operating lift. Keep this manual near lift at all times. Make sure all operators read
this manual.
5. NOTE: Are you installing in a level location? (Lift must be anchored in place
if slope is greater than 1/8" per foot.)
6. Make sure you have enough room to install the lock rods. You will need at least
9’ of clearance from the opposite end of the power unit end of the lift and 6’
at the power unit end. (See floor plan on page 6). The power unit may be
installed on the driver’s front or the passenger rear corner.
7. Never raise a car until you have double checked all bolts, nuts and hose fittings.
8. Always lower the lift to locks before going under the vehicle or storing another
vehicle underneath lift. Never allow anyone to go under the lift when raising or
lowering.
This is a vehicle lift installation/operation manual and no attempt is made or implied herein to
instruct the user in lifting methods particular to an individual application. Rather, the contents of
this manual are intended as a basis for operation and maintenance of the unit as it stands alone or
as it is intended and anticipated to be used in conjunction with other equipment.
Proper application of the equipment described herein is limited to the parameters detailed in the
specifications and the uses set forth in the descriptive passages. Any other proposed application
of this equipment should be documented and submitted in writing to the factory for examination.
The user assumes full responsibility for any equipment damage, personal injury, or alteration of
the equipment described in this manual or any subsequent damages.
