PP8 Plus 33 IN50001 Rev. C 04/30/2008
86 B10-6×30 Hex Head Bolt M6×30 4
87 B41-6 Flat Washer
Ø
612
88 B84-35 Plastic Knob For Handle Ø 35×M10 1
89 B23-6×10 Discal Head Screw M6×10 4
90 DP8-3014 Angle Iron 4
91 B41-5 Flat Washer
Ø
520
92 B41-20 Flat Washer
Ø
20 8
93 H4D-7000-05 Steel Spacer 2
94 30400-1999 Washer 4
95 DP8-3015 Flat Washer
Ø
30C Level 2
96 H4P-R3100 Wheel Chock 2
97 H4P-R3101 Angle Iron 2
98 H4P-R3102 Rubber 8
99 B23-5×16 Discal Head Screw M5×16 8
100 B30-5 Nut M5 8
101 B10-8×40 Hex Head Bolt M8×40 4
102 B33-8 Nylon Lock Nut M8 4
PP8P-7000CK Caster Kit - Assembly 4
1 PP8S-2000 Caster Kit - Frame Weldment 4
2 B80-6×2A Caster Kit - Caster Wheel Assembly 6"×2" 4
3 PP8S-2100 Caster Kit - Hitch Pin 4
4 H4D-5006-03 Caster Kit - Hairpin Clip 4
5 B30-10 Hex Nut - M10 16
6 B40-10 Lock Washer - Ø10 16
7 B41-10 Flat Washer - Ø10 32
8 B10-10×35 Hex Bolt - M10×35 16
DP7PNBKD-DT Drip Tray 3
H4D-6000 Jack Tray / Tool Box 1
Accessories for PP8P
