SPECIFICATIONS
18
© 2002 Directed Electronics, Inc
1400 watts
0.8% THD
Directed model 2400d
Signal-to-Noise Ratio Greater than 80 dB
Frequency Response 20-250 Hz +0, -1 dB
Damping Factor 50 (typical)
Crossover Low-pass 18 dB/octave,
variable from 30 to
250 Hz
Subsonic Filter Switchable 30 Hz
24 dB per octave
Bass Equalization Switchable 8 dB,
centered at 40Hz
Input Impedance 20K ohms
Input Sensitivity Variable from 150 mV
to 8 volt
Output Impedance 2 to 4 ohms
Supply Voltage 10 to 16 VDC
Fusing and Power 200A
Minimum Cable Requirements (AWG) (+) 12 Volt #0 Battery to fuse block
(Per amp, trunk mounted) #4 Fuse block to
amplifier
Minimum Cable Reguirements (Ground) #4 Amplifier to chassis
2600 watts
2400 watts
1.0%
THD
RMS continuous power driven into 4 ohms from 20 to 250
Hz @ 14.4 VDC at rated power/load.
RMS continuous power driven into 2 ohms from 20 to 250
Hz @ 14.4 VDC at rated power/load.
Dynamic power rating (IHF-202 Standard) minimum load.
