SPEAKER WIRING DIAGRAMS
Speaker nominal impedance must be at
least 2 ohm. Amplifier parallels the
speaker terminals internally.
Single subwoofer connection
Two subwoofer connection
Parallel speaker nominal impedance must
be at least 2 ohm. Amplifier parallels the
speaker terminals internally.
