Directed Electronics Xpresskit Series User Manual

SWITCHING BETWEEN MODES
1. Remove power to the XL202 module.
2. Press and hold the Programming button.
3. Reconnect the XL202 module, while still holding the Programming button. The LED turns on solid.
4. Release the button, then press and hold it once again. The LED turns off/on following the sequence.
If you hold the button longer than 5 seconds, it will erase all the memory content.*
5. After 2 seconds, the XL202 turns off the LED and switches mode. You can release the button and watch the LED:
- Mode 1
1x slow LED flash = LCD (XRT) remotes
- Mode 2
2x slow LED flash = Non-LCD remotes
Once the mode is changed, it erases all memory content and reverts to normal operation by itself. No more manipulation is
required, other than learning the remote.
* Erasing all remotes from memory:
1. Remove power to the XL202 module.
2. Press and hold the Programming button, while reconnecting the power to the XL202 module.
3. Keep holding the Programming button. The LED will stay on for 5 seconds, then it will start to flash quickly.
4. You can now release the button.
Once the module stops flashing, the memory content has been erased. The next step is to program all desired remotes.
Page 3
Rev.: 20091124
© 2009 Directed Electronics. All rights reserved.
MODEL: XL202
FIRMWARE: RFTDAF
