SPECIFICATIONS
Xtreme models 1500X 1800X 2300X 2600X 4600X
Type Mono block Mono block 2-channel 2-channel 4-channel
Maximum Power 500 watts 800 watts 300 watts 600 watts 600 watts
Damping Factor >50 >50 >50 >50 >50
Frequency Response 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz
+/- 1dB +/- 1dB +/- 1dB +/- 1dB +/- 1dB
Crossover (12dB Slope) LP 50-500Hz LP 50-500Hz Variable Variable Variable
HP/LP HP/LP HP/LP
50-250Hz 50-500Hz 20-500Hz
Bass EQ (@ 50Hz) Switch Switch Switch Switch Switch
+6/+12dB +6/+12dB +6/+12dB +6/+12dB +8dB
Input Sensitivity 200mV-4V 200mV-4V 100mV-4V 130mV-4V 100mV-4V
Protection Thermal, Overcurrent, Short Circuit, Reverse Polarity
Fuse Size 15A x 2 30A x 2 25A 20A x 2 25A x 2
Minimum Power Wire Gauge 12 10 12 12 12
