DirecTV STREAM - Client Hardware Components; Front Panel Indicators; Side Panel Features; Rear Panel Ports and Interfaces

7
Version 4.0 09/2021
B. Client Hardware
1. Front Panel
• Blue Power Status Indicator LED • Green / Yellow / Red Network Status Indicator
FIGURE 1: DIRECTV STREAMFRONT PANEL
2. Side Panel
• Red Reset Button
FIGURE 2: DIRECTV STREAMSIDE PANEL
3. Rear Panel
• 10/100 Ethernet Connector with Indicator LED
• S/PDIF Optical Audio Connector
• HDMI Connector (Type A)
• USB 2.0 Port (Type A Connector)
• DC Power Inlet Connector
(for EPS10 External Power Supply)
with Power Indicator LED
FIGURE 3: DIRECTV STREAMREAR PANEL
