SPLIT
19
EN
Air conditioning for vehicles
CABLING DIAGRAM
connect to pressuriser

Connection +

EVAPORATOR
Connect to sensor with green adhesive
(recirculation)
connect to
sensor with
red adhesive
(anti-freeze)
Connect to
the electro
wire clamps
Connection

Connection


COMPRESSOR MOTOR
CONDENSER
CONTROLS
rele
rele
rele
RELAYS
