5
ASSEMBLY
CAUTION: Always disconnect the appliance from the electric
outlet before assembling or disassembling unit or accessories.
ATTENTION:
Do not allow the vacuum to remain in one spot for any length of time when
the brush roller is turning. Damage to carpet may occur.
v
NOTE:
To remove the handle from the main body, pull the lock switch
outwards and pull the handle assembly out of the main body.
NOTE: Six bright LED lights on oor head help
illuminate the cleaning path while operating.
Close lock
switch until
it clicks
u
Insert the end of the handle into the main body. Then, lift lock switch upward
until you hear a “click” to secure handle.
B
Attach the FLOOR HEAD to the open end of the dust bin aligning the two pins
to the holes. Proper connection is needed to operate the LED lights and oor head
for carpeted and hard surface oors.
TO DISCONNECT, unplug unit from power outlet and remove the oor head by
pulling it apart from the dust bin.
C
B
B
A
C
A
B
A
A
